Thermal camera Dahua HY-FT431LDP-TD1F4-MB
€249.90
Tax included
Secure payments
SSL-secured connection, cash on delivery payment.
Fast delivery
Delivery nationwide – arranged after the order.
Returns
14-day right of withdrawal under consumer protection law.
General
| Type | Eyeball |
| Series | Thermal |
| Color | Red |
| Image sensor | Thermal camera with Vanadium Oxide Uncooled FPA technology + 1/2.7" 4 Megapixel visible camera |
| Resolution | 4M (2688 × 1520) |
| Effective pixels | 4 |
| Scanning system | Progressive |
| Electronic shutter speed | Auto/ Manual 1/3 s–1/100000 s |
| Minimum illumination | Color: 0.0052 lux B/W: 0.0028 lux 0 lux (IR on) |
| Day/night modes | Auto (ICR) / Color / B&W |
| IR illumination up to | 15 |
| IR On/Off Control | Manual/Auto |
| IR LEDs | 1 |
| Storage | FTP; NAS; SFTP |
Camera
| IRE | 30, 0Lux IR on |
| Signal-to-noise ratio | > 55dB |
| Thermal camera specific features | Pixel pitch: 17 μm, Spectral range: 8 μm–14 μm; Sensitivity (NETD): < 60mK (@f/1.0, 300K); Color palettes: 12; Temperature range: -10°C to +200°C |
Lens
| Lens | Fixed |
| Focal length | Thermal camera: 1.2 mm + Visible camera: 4 mm |
| Max. aperture | Thermal camera: F1.1 + Visible camera: F1.6 |
| Field of view | Thermal camera H: 90° + Visible camera H: 85° |
| Minimum focus distance | Thermal camera: 0.5 m + Visible camera: 1 m |
Video
| Frames per second | Main stream: 1 fps–25 fps adjustable, 25 fps by default Sub stream: 1 fps–25 fps adjustable, 25 fps by default |
| Video compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Streaming capability | 2 streams |
| Bandwidth | 100 Mbps incoming |
| BLC | BLC / HLC / WDR |
| WDR | DWDR |
| White balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street light |
| Gain Control | Auto / manual |
| Noise reduction | 2D NR/3D NR |
| Image rotation | 0°/90°/180°/270° |
| Privacy masks | 4 zones |
Perimeter protection
| AI features | Privacy masking, Fire detection |
Certification
| Certifications | CE |
Additional ports
| Audio input | 1 channel: built-in microphone |
| Audio output | 1 channel: built-in speaker |
| Alarm input | 1 input: 5mA 3V–5V DC |
| Alarm output | 1 output: 300mA 12V DC |
| Audio compression | MPEG2-Layer2; G.711a; G.711mu; AAC; PCM; G.722.1; G.726 |
| Built-in microphone | yes |
| Built-in speaker | yes |
| Built-in siren | Yes, 70dB |
Network features
| Ethernet | 1 RJ-45 Ports (10/100 Mbps) |
| Network protocols | HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP |
| Compatibility | ONVIF; GB/T28181; CGI; Imou |
| Max. number of users | 10 |
| Web browser live view | Chrome; IE9 or later; Firefox |
Power supply
| Power supply | 12 VDC (±30%); PoE (802.3af) |
| Power consumption | < 3W |
Operating conditions
| Operating temperature | -10°C to +55°C |
| Operating humidity | < 95% RH |
| Storage temperature | -20°C to +70°C |
| Protection rating | IP66 |
Construction
| Dimensions | Ø109.9 mm x 90.1 mm |
| Net weight | 0.35 kg |
| Gross weight | 0.5 kg |
