- New
Magnetic card reader Dahua ASI1201M-MEP - PoE
€133.62
Tax included
Secure payments
SSL-secured connection, cash on delivery payment.
Fast delivery
Delivery nationwide – arranged after the order.
Returns
14-day right of withdrawal under consumer protection law.
| Brand | DAHUA |
General
| Type | Standalone controller |
| Material | PC and zinc alloy |
| Operating frequency | 13560 and 125 kHz |
| Waterproof | IP65 |
| Supports up to | 10000 cards |
| Max. number of users | 10000 users |
| Max. number of passwords | 10000 passwords |
| Max. number of records | 100000 records |
Features
| Automatic registration | yes |
| Network | 1 RJ-45 (10 Mbps/100 Mbps) |
| RS-485 | 1 |
| Wiegand | 1 |
| Alarm input | 2 |
| Alarm output | 1 |
| Exit button | 1 |
| Door status detection | 1 |
| Tamper | yes |
| Electric lock control | yes |
| Audible indication | yes |
| Light indication | yes |
| NC contact | yes |
| NO contact | yes |
| Alarm function | yes |
| User registration via | Master card |
Technical
| Programming | Via master cards |
| Reading distance | 0 - 30 mm |
| Operating voltage | DC 12V, 0.5A, PoE |
| Operating consumption | 18 W |
| Mounting | Surface mount |
| Operating temperature | –30°C to +60°C |
| Operating humidity | 5%RH–95%RH (non-condensing) |
| Certifications | CE |
| Dimensions | 169 × 57.5 × 33.3 mm |
